An Essential Guide to Working with Polyester Resin and MEKP Catalyst 🛠️

An Essential Guide to Working with Polyester Resin and MEKP Catalyst 🛠️

Polyester resin is a versatile and durable material widely used in a variety of projects, from boat repair and fiberglass lamination to creating waterproof coatings for wood. When combined with its essential partner, MEKP (Methyl Ethyl Ketone Peroxide) catalyst, it cures into a hard, resilient plastic. This guide provides a comprehensive overview of how to safely and effectively mix and use polyester resin for your outdoor furniture, boat repair, and other DIY projects.

Understanding the Materials 🧪

Polyester Resin: This is a thermosetting plastic that starts as a viscous liquid. It's known for its strong adhesion, water resistance, and ability to be sanded and painted. Some common types are orthophthalic resin, suitable for general-purpose applications with good water resistance. For projects requiring greater durability or chemical resistance DCPD resin, or dicyclopentadiene resin is a type of thermoset resin known for its exceptional properties, particularly in applications requiring high heat and chemical resistance, as well as good mechanical strength and low shrinkage.

MEKP Catalyst: This is the crucial component that initiates the chemical reaction, or "curing," of the resin. It's a hazardous substance that requires careful handling. Without the proper amount of MEKP, the resin will never fully harden. Too much, however, can lead to a dangerously fast and brittle cure, or even a fire.

Safety First: Your Most Important Step ⚠️

Working with polyester resin and MEKP requires strict safety precautions:

  • Ventilation: Always work in a well-ventilated area to avoid inhaling the strong fumes. An open garage with a fan or an outdoor (covered) workspace is ideal.
  • Personal Protective Equipment (PPE):
    • Gloves: Nitrile gloves are recommended or latex gloves.
    • Eye Protection: Wear safety goggles / glasses to protect your eyes from possible splashes.
    • Respirator: A respirator with organic vapor cartridges is essential to protect your lungs from inhaling harmful fumes.
    • Clothing: Wear long sleeves and pants to protect your skin, and consider an apron to protect your clothes, or a disposable set of coveralls.
  • Fire Safety: Keep a fire extinguisher nearby. MEKP is highly flammable and can react violently with certain materials. Never store MEKP near heat sources or in direct sunlight.

Mixing the Resin and Catalyst 💧

The correct ratio of MEKP to resin is critical. The general rule is to add 1-2% MEKP by volume to the resin. This translates to roughly 1 teaspoon of MEKP for every 1 cup of resin. However, always consult the instructions and the ratio chart provided on Lab X Creation’s lines of polyester resin that we offer, as the ideal ratio can vary depending on the product and ambient temperature. For heat over 87° you may want to limit your MEKP to 1% to prevent early gelling or thermal runaway (premature catalyzation/curing)

Factors Affecting Cure Time:

  • Temperature: Warmer temperatures and direct sunlight accelerate the curing process, while colder temperatures slow it down. Be sure to avoid temperatures below 70°F, even for overnight temperatures as that will extend out the time needed for a complete cure.
  • Humidity: High humidity can affect the surface cure, leading to a tacky or "sticky" finish, tenting the area and/or providing heat overnight can push the moisture out and avoid this complication.
  • Catalyst Ratio: A higher percentage of MEKP will result in a faster cure, but increasing the catalyst beyond the recommended maximum can lead to a brittle, compromised final product. Lab X Creations does NOT recommend exceeding 2.25% by volume of catalyst.

Mixing Process:

  1. Measure the desired amount of resin into a clean, disposable container.
  2. Carefully measure the correct amount of MEKP catalyst using a graduated dropper or measuring syringe, we provide graduated pipettes with each order. Never use the same measuring tool for both resin and catalyst without thoroughly cleaning it.
  3. Add the catalyst to the resin and stir slowly but thoroughly for at least one minute. Use a clean stir stick, ensuring the catalyst is evenly distributed throughout the resin. Scrape the sides and bottom of the container to mix everything completely. Skipping the scraping steps as you mix will lead to uncatalyzed resin.
  4. Once mixed, the resin will have a limited "pot life" or "working time"—the time you have to apply it before it begins to cure and become unworkable. This is typically 15-30 minutes, depending on the factors mentioned above.

Applications: Coating Wood, Laminating Fiberglass, and More 🪵

Coating Wood and Plywood

Polyester resin can be used to create a hard, waterproof surface on wood, making it ideal for outdoor furniture, tabletops, and marine applications.

  1. Prepare the Surface: Ensure the wood is clean, dry, and free of any dust, oil, or old finishes. Sand the surface lightly to provide a good "tooth" for the resin to adhere to (180 or lower grit sandpaper is recommended).
  2. Apply the Resin: Use a brush, roller, or squeegee to apply a thin, even coat of the mixed resin to the wood. Letting the first coat sit for 5-10 minutes will assist with seeing what parts of the wood surface will soak up the most resin and where more may need to be applied.
  3. Multiple Coats: For a durable finish, apply multiple thin coats, allowing each coat to become tacky but not fully cured before applying the next. This creates a strong chemical bond between layers. Using a heat gun to assist with releasing any bubbles will ensure a strong and durable coating.
  4. Finishing: Once the final coat is cured, sand the surface smooth and apply a gelcoat or paint if a finished color is desired.

Laminating Fiberglass

Fiberglass lamination is a key application for polyester resin, used in boat repairs, building custom parts, and reinforcing structures.

  1. Prepare the Mold or Surface: The surface should be clean and smooth. For boat repairs, clean the damaged area and sand it to create a rough surface. If cracks are present making a V shaped cut or grind will ensure resin penetration and a stronger repair.
  2. Cut the Fiberglass Mat/Cloth: Cut the fiberglass to the desired size and shape. Over laying a small extra border is preferred as it will allow for blending and ensure long fibers exist as far out as possible.
  3. Apply the First Layer: Apply a thin layer of catalyzed resin to the surface with a brush or roller.
  4. Lay the Fiberglass: Lay the fiberglass mat or cloth onto the wet resin, pushing it lightly into the resin to hold it in place.
  5. Saturate and Roll: Apply more resin over the fiberglass and use a laminating roller or stiff brush to fully saturate the material. Roll out any air bubbles (bubble rollers are great for this), as these can weaken the bond of the laminate.
  6. Build Layers: Repeat the process with additional layers of fiberglass and resin until the desired thickness is achieved. Keep in mind that it’s easy to sand to the final desired shape or height but further makes it difficult if more needs to be added later.

Cleanup and Disposal 🚮

  • Cleanup: Clean tools immediately after use with acetone. Once the resin cures, it is almost impossible to remove. For larger layups or projects cleaning the tools intermittently is recommended.
  • Disposal: Dispose of uncured resin and catalyst according to local hazardous waste regulations. Never pour them down a drain. Catalyzed / cured resin is a solid and can be disposed of in the regular trash.

By following these guidelines, you can safely and effectively use Lab X Creations polyester resin and MEKP catalyst to tackle a wide range of outdoor projects, extending the life and durability of your wooden furniture, and making professional-grade repairs to boats and other fiberglass items. Always remember that careful measurement, a strong focus on safety and complete preparation of your project are the keys to a successful project.
